Consulting Services
One Stop solution for Busduct System
- It is the 1st Step in interaction with Expert about the required solutions for your Project.
- We offer Consultancy for Power distribution and dedicated solution for Busbar Trunking.
- Customized solution compatible for your need and project Site.
- Product Selection to achieve optimum level of Electrical Safety.
- Space requirements to install & trouble operation in Long Run.
- One Point Connect to interact equipment supplier and agencies.
- We care INNER HEALTH of Installation to ensure Safety and serving of responsibilities being an Engineer.
- Call to Expert +91 18005700126 or Write us on ashok.sahu@busway-electric.com.
Busduct -IP55
Feeder Busduct
- Rating 400A to 6300A available for Primary LT Distribution as a Feeder.
- Aluminium and Copper Conductor both options are available.
- Suitable for Indoor [IP54] and Outdoor [IP65] applications.
- Benefits Low Impedance, maintenance Free compact Solution and High Fault withstand Capacity.
- Straight Feeder, Elbow, Flange, Cu Braided Flexibles are the Key Elements.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Busduct-IP65
LT Busduct for Sub-station
- Rating 400A to 6300A available for Primary LT Distribution as a Feeder.
- Aluminium and Copper Conductor both options are available.
- Suitable for Outdoor [IP65] applications.
- Benefits Low Impedance, maintenance Free compact Solution and High Fault withstand Capacity.
- Canopy for Outdoor Installation is always Recommended.
- Sandwich Type IP66, Cast Resin IP68
- Straight Feeder, Elbow, Flange, Cu Braided Flexibles are the Key Elements .
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Rising Mains-IP-54
Component level of attention in offering Busduct Solution
- Busduct & Busbar Trunking: Lighting Busway, Track Busway for Data Centre, Air-insulted, Sandwich, Cast Resin Busduct, Non-segregated Phase & Segregated Phase Busduct, Isolated Phase Busduct [HV]
- LT Switch Gear : LT Panel, APFC Panel, Air circuit Breaker [ACB], Moulded Case Circuit Breaker [MCCB], Miniature Circuit Breaker [MCB], High Rupturing Capacity Fuse[ HRC Fuse].
- Wires & Cables : Power Cables- Single/ multicore, Control & Instrumentation Cables, Communication & Networking Cables, Fire Survival Cables. Complete cable Solutions
- Cable Management: Wire mesh Cable Tray, Cable Gland, Lug, Cable Tie, Complete Cable Termination accessories.
- Earthing & Lightning Protection : Safe Earthing Electrode, Back Fill Compound, Earth Wire, Lightning Arrestor, Complete Earthing Solution.
- We offer Consultancy, Layout Design & Engineering, Supply and Installation & Testing & Commissioning.
- Write us at: sales@busway-electric.com or call us on Toll Free No- 1800 570 0126.
- Busway Electric Team Happy to Konnect with you and ensure the Best Solution.
Busbar Trunking
Busduct Expert
- We offer Consultancy, Layout Design, Supply of Busduct, Install, Testing & Commissioning.
- Having 15+ Yrs of Expertise in Design & supply Products in Residential, Office Building, Commercial Building, IT Parks, Industries, Metros.
- Preparing Site Layout Drawing is Key Important for Busduct Solution.
- Preparing Layout autocad drawing as per actual site condition with Precision for Manufacturing.
- Coordination with Manufacturer to ensure the manufacturing as per approved Layout.
- Factory Inspection for you to ensure the Dispatch of Right Product complying technical aspects.
- Coordination for Installation, Testing & Commissioning.
- Product Training to Site Team for Handing Over.
- Connect us and reshape your Distribution Scheme with Busway-Electric.
- Offering Services for Busduct OEM, Architect & Consultant, Contractor & End User.
- We are working towards Enhancing Safety in Building Infrastructure.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Non-Phase Segregated Busduct
LT /HT Application
- Rating 415V, 50 Hz, 400A to 8000A LT Distribution as a Feeder.
- Interleaved Design above 1600A duly Type Tested.
- Rating 3.3KV, 6.6KV 50 Hz, 630A to 5000A HT Feeder.
- Aluminium and Copper Conductor both options are available.
- Suitable for Indoor/Outdoor [IP54/55] applications.
- Suitable for AC & DC Rectifier for Metro Application.
- Canopy for Outdoor Installation is always Recommended.
- Straight Feeder, Elbow, Flange, Cu Braided Flexibles are the Key Elements.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Copper Braided Flexibles
Cu Braided Flexible
- Cu Braided Flexibles are used for End Termination in the Busduct.
- Electro-tinned Braide with Silver Plated Socket upto 6300A rated Current .
- We are not recommending Al/Cu shorting Links for Termination.
- Completely customized Design of flexibles to ensure Safety & trouble free operation in long run.
- Suitable for All types of Busduct i.e Sandwich, Cast Resin & Air-insulated, Segregated and Non- segregated Busduct.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Cu Laminated Flexible
- Cu laminated Flexibles are used for End Termination in the Busduct specially in high current requirements i.e Furnace Transformer , Busduct connections.
- Electro-tinned Braide with Tin/ Silver Plated Socket upto 6300A rated Current or More.
- Thickness of Each Sheet is 0.2 mm and stacked as per thickness /current rating.
- Completely customized Design of flexibles to ensure Safety & trouble free operation in long run.
- Suitable for All types of Busduct i.e Sandwich, Cast Resin & Air-insulated, Segregated and Non- segregated Busduct and Industrial application.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Cu Laminated Insulated Flexible
- Cu laminated Flexibles are used for End Termination in the Busduct specially in high current requirements i.e Furnace Transformer , Busduct connections.
- Electro-tinned Braide with Tin/ Silver Plated Socket upto 6300A rated Current or More.
- Thickness of Each Sheet is 0.2 mm and stacked as per thickness /current rating.
- Completely customized Design of flexibles to ensure Safety & trouble free operation in long run.
- Suitable for All types of Busduct i.e Sandwich, Cast Resin & Air-insulated, Segregated and Non- segregated Busduct and Industrial application.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Cu Laminated Flexible
- Cu laminated Flexibles are used for End Termination in the Busduct specially in high current requirements i.e Furnace Transformer , Busduct connections.
- Electro-tinned Braide with Tin/ Silver Plated Socket upto 6300A rated Current or More.
- Thickness of Each Sheet is 0.2 mm and stacked as per thickness /current rating.
- Completely customized Design of flexibles to ensure Safety & trouble free operation in long run.
- Suitable for All types of Busduct i.e Sandwich, Cast Resin & Air-insulated, Segregated and Non- segregated Busduct and Industrial application.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Rubber Bellow & Adopter Box
- Quality Product need Expert Team to ensure the design and execution considering the safety at Component level.
- Expert Team to collect Site inputs to design customized Accessories.
- Adopter Box are playing Key Role in End Termination and Providing space for it.
- Adopter Box available duly Powder Coated made from Sheet Steel from 2 mm Thickness.
- Rubber Bellow for Transformer and D.G connection recommended to absorb the vibration.
- Rubber Bellow also available on fully customized design to meet site requirements.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Canopy
- Busduct Installation for Outdoor sub-station over to sky recommend External Canopy.
- Canopy design considering the parameter of Cooling of Busduct and its Protection from Rain Water and Rays from Sun light.
- Made from 1.5 to 2mm sheet Steel duly Powder Coated.
- Protection Transformer LT Box also Include in the scope.
- Proper support to Canopy and necessary earthing as per Guidelines.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Rising Main-IP54
Vertical Distribution
- Rating 250A to 6300A available for Vertical Distribution and feeding 3Phase Power to Floor DB / Panel.
- Conductors are made from Aluminium and Copper materials.
- Suitable for Indoor [IP54]
- Benefits Low Impedance, maintenance Free compact Solutions.
- Straight Feeder, Elbow, End feed Unit , Tap-off Boxes, Plug in Box are the Key Elements.
- Thermal Expansion Elements also required.
- Rating Reducer: We are not suggesting direct reducer.
- We help you in Layout design, Product Selection , competitive price offer and installation.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Track Busway [Data Centre]
Critical Application
- Rating 160A to 1000A available for Horizontal Distribution in Data Centre considering Critical Application.
- Special Plug-in Box to Feed Power to Server Rack via suitable Detachable Power Sockets.
- Conductors are made from Copper materials.
- Suitable for Indoor [IP54]
- Benefits Low Impedance, maintenance Free compact and Reliable Solution.
- Straight Feeder, Elbow, End feed Unit , Tap-off Boxes, Plug in Box are the Key Elements.
- We help you in Layout design, Product Selection, competitive price offer and installation and after sales Service.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Lighting Busway
Final distribution
- Rating 25A, 40A for final distribution of Power to Lighting Loads for Group control.
- Suitable for Parking, Warehousing, Metro Rail, Infrastructure Projects, Assembly Lines etc.
- Simple in design and easy to install and Operate.
- 10A plug used for connecting lamps/Load.
- Conductors are made from Copper materials.
- Suitable for Indoor [IP54]
- Benefits Low Impedance, maintenance Free compact and flexible Solution.
- Straight Feeder, End feed , Plugs are the Key Elements.
- We help you in Layout design, Product Selection, competitive price offer and installation and after sales Service.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Rising Mains Accessories
End Feed Panel
- Available from 250A to 6300A Rating.
- End Feed Panel 415V, 50Hz , 4P, 3P+N+Pe compatible for All Leading Brand.
- Customized design for different Projects to make it compatible for Proper Cable Termination from Bottom.
- Braided Cu Flexible used for Connection Between MCCB & Flange.
- Provision for Air Circuit Breaker, MCCB, Change Over Switch, Switch Disconnector & HRC Fuse.
- Provision for Metering devices Dual Source Energy Meter, Ammeter, Voltmeter etc.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Tap-off Boxes
- 32A to 1250A rating Tap-off boxes with Protection.
- Plug-in Boxes are available with MCB, MCCB.
- Options for HRC, Metering in the Plug in Box are available.
- Tap-off boxes are Key Elements in Bus Trunking System and carefully selected for Design & Protection.
- Safety should be in high priority while product selection otherwise objective will never achieve to enhance Safety.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
Customized End Feed Unit
- Offer customized End Feed Unit compatible for All Manufacturers.
- Cu Braided Flexibles are used to connect Busway Flange with MCCB Terminals.
- Electro-tinned Braide with Silver Plated Socket upto 6300A rated Current.
- Site inputs by Busway Expert.
- Completely customized Design to ensure Safety.
- We ensure Technically Sound Termination.
- Suitable for All types of End Feed Unit i.e MCCB, ACB, Switch Disconnector Fuse.
- Call to Expert 1800 570 0126 or Write us on sales@busway-electric.com.
